504X Fluid Video Head with flat base
MVH504XAH
Product features
-
Variable fluid Drag System on PAN & TILT, performed by new fluid
-
4 steps counterbalance system up to 14.3 lbs
-
Flat base for shooting on sliders, jibs or other accessories
-
Sliding plate side lock attachment
-
Highest safety standards ensured by UNI/PdR 105:2021 compliance
Designed in Italy
Highest protection. Backed by warranty. Learn more
Find Online
Product overview
504X fluid video head is the evolution of the hugely successful 504HD.
It's a more compact and lighter version that finally comes with flat base (base diameter 75 mm), developed to meet the needs of the most demanding videographers.
The head is made from a brand-new catching aluminium design, and has a maximum payload of 26.4 lbs.
Utilising Manfrotto’s new fluid technology, the camera head allows you to capture judder-free smooth motion pans and tilts. It's never been easier for the operator to create premium-quality video capture, thanks to a 4-step counterbalance system which can carry payloads of up to 14.3 lbs at 55mm C.0.G. That makes using a wide range of different cameras easier and more practical.
Two easy link 3/8'' thread connections allow an external monitor or other accessory equipment to be fitted on the head side. On the left side there is a cap cover on the 3/8” easy link connector to avoid cutting during usage.
The sliding-plate side-lock attachment enables quicker set up of the camera, keeping video equipment stable and balanced. Head leveling is simple thanks to the clever backlit levelling bubble.
It's a more compact and lighter version that finally comes with flat base (base diameter 75 mm), developed to meet the needs of the most demanding videographers.
The head is made from a brand-new catching aluminium design, and has a maximum payload of 26.4 lbs.
Utilising Manfrotto’s new fluid technology, the camera head allows you to capture judder-free smooth motion pans and tilts. It's never been easier for the operator to create premium-quality video capture, thanks to a 4-step counterbalance system which can carry payloads of up to 14.3 lbs at 55mm C.0.G. That makes using a wide range of different cameras easier and more practical.
Two easy link 3/8'' thread connections allow an external monitor or other accessory equipment to be fitted on the head side. On the left side there is a cap cover on the 3/8” easy link connector to avoid cutting during usage.
The sliding-plate side-lock attachment enables quicker set up of the camera, keeping video equipment stable and balanced. Head leveling is simple thanks to the clever backlit levelling bubble.
Specifications
Weight:
2 kg
Safety Payload UNI/PdR 105:2021:
12 kg
Counterbalance System:
Variable Steps
Counterbalance Weight:
2.2, 4.4, 6.5 kg
Base Diameter:
75 mm
Downloads
MVK500XAM
Manfrotto_Compatibility-chart_Sliding-Plates..pdfMVH504XAH
MVH504XAH_20241114.pdfMVH504XAH
MVH504XAH_20240326.pdfSpare part_20210120
MVH504XAH_20210120.pdfSpare part_20230821
MVH504XAH_20230821.pdfSpare part_20230822
MVH504XAH_20230822.pdfPatent MVH504XAH
patent_MVH504XAH_2024-08-30-10-55-58.pdfCounterbalance-graph_504X-FLUID-VIDEO-HEAD
Counterbalance-graph_504X-FLUID-VIDEO-HEAD.pdf
Warranty
Manfrotto Video Accessories are covered by a Standard Limited Warranty (two years from date of purchase) and are eligible for a free Standard Limited Warranty Extension, upon online product registration, for an additional three years - thus up to five years from date of purchase. For more details or to register your product, please visit: warranty.vitecimagingsolutions.com.
